Tire Changers
BD15
Leverless Table-Top Tire Changer
Rim Range 13–28''Powers 0.75 / 1.1 kWVoltages 220V / 380VMax. Wheel Diameter 1080 mm
Specifications
BD15 specs
Rim Range
13–28''
Rim Width
350 mm
Max. Wheel Diameter
1080 mm
Work Pressure
8–10 bar
Voltages
220V / 380V
Tire Lift Max Loading
75 kg
Noise
<70 dB
Operation Speed
6/12 rpm (380V)
Powers
0.75 / 1.1 kW
N./G. Weight
368 / 430 kg
Machine-Space DIM
1800 × 1800 × 2200 mm
Packing DIM
1380 × 1130 × 1840 mm
Max QTY In Container
8 pcs (20'') & 16 pcs (40'')
Resources
Docs & media
📄
User manual
Installation, operation and maintenance documentation for the BD15.
Request manual from export team →▶
Product video
See the BD15 in operation.
⏳ Video coming soonFeatures
What sets it apart
01
Crowbar-free bird head reversal
Automatic bird head reversal with extended tire removal hooks.
02
Reversing switch
Enables easy direction reversal to enhance operational flexibility and efficiency.
03
High-performance integrated motor
Real-time load-based adjustment to improve energy efficiency and reduce energy consumption.
In the crate
Accessories
Standard
Tire PresserPlastic CrowbarCaliperUniversal Fixture AdaptorConeBird's Head GasketTire Shovel Sleeve
Quote the BD15 for your market.
Send your country and quantity — our export team replies with pricing, lead time and container loading.
